Water Filled Submersible Pump

Name: Water Filled Submersible Pump
Brand: JAGGI INDUSTRIES
Price: 8000 INR
Availability: InStock

Price 8000 INR/ Piece

Get a Price/Quote

MOQ : 100 Pieces

Water Filled Submersible Pump Specification

Inlet/Outlet
32 mm x 32 mm

Mounting Type
Vertical

Features
Rust Resistant, Energy Efficient, Overload Protector

Working Temperature
Up to 40C

Head Size
Up to 52 meters

Caliber
32 mm

Flow Rate
45-120 LPM

Max Suction
NA (Submersible type)

Speed
2880 RPM

Voltage
220-240 V

Noise Level
Low

Control System
Manual / Automatic

Theory
Centrifugal Pump

Frequency
50 Hz

Discharge Pressure
Up to 7 Bar

Material
Stainless Steel

Structure
Multistage / Monoblock

Power
Electric

Product Type
Submersible Pump

Fuel Type
Electric

Pressure
High

Usage
Water Supply, Irrigation

Application
Agriculture, Domestic, Industrial

Suction Type
Submersible

Seals Type
Mechanical Seal

Priming
Self Priming Not Required

Pump Type
Water Filled Submersible Pump

Capacity
Up to 8,000 LPH

Protection Class
IP68

Maximum Submersion
Up to 50 meters

Cable Length
Up to 100 meters

Enclosure Type
Hermetically Sealed

Minimum Water Depth
1 meter

Impeller Material
Noryl / SS

Bearing Type
Heavy Duty Ball Bearings

Water Filled Submersible Pump Trade Information

Minimum Order Quantity
100 Pieces

Supply Ability
100 Pieces Per Day

Delivery Time
10 Days

Sample Available
Yes

Sample Policy
Sample costs shipping and taxes has to be paid by the buyer

Main Domestic Market
All India

About Water Filled Submersible Pump

Submersible Pumps (Water Filled) :

(CONFORM TO IS: 8034)

Since the year 1994, we have been engaged in offering our esteemed clients premium quality Submersible Pump. Our offered pump is widely used in water supply for bungalows, refrigeration industry, water treatment plants and housing complexes. This pump also find its applicability in various dairies, cattle farms, agricultural use, farms & nurseries and other related areas for water suction purposes. We offer this Submersible Pump in different capacities in order to suit he requirements of the clients.

Salient Features:

Pump works under water and hence suction and priming problems do not arise
Water cooled, rewind able induction motor
Rotor laminations are fitted with copper strips and mounted on a stainless steel shaft
Maintenance free operations due to water lubricated Leaded Tin Bronze (LTB) thrust and bush bearing
Noiseless operation
Stainless steel body for motor and pump portion

Applications:

Industrial and civil applications
Agricultural applications
Domestic water supply
Multi-storied buildings
Fountains

Particulars	(Single Phase)	(Three Phase)
Power Range	0.5 HP to 3.0 HP	1.0 HP to 7.5 HP
Supply	240 V, 50 Hz	415 V, 50 Hz
Speed	2800 rpm	2800 rpm
Discharge Range	16 LPM to 400 LPM	16 LPM to 400 LPM
Total Head Range	6 M to 250 M	6 M to 250 M
Pipe Size	32 mm, 38 mm, 50 mm	32 mm, 38 mm, 50 mm

Note: Due to continuous efforts in improvements, information furnished above is subject to change without notice.

High Performance in Deep Water Applications

With a maximum submersion depth of 50 meters and the capability to supply up to 8,000 liters per hour, this submersible pump is perfect for deep wells and high-demand systems. Its robust construction supports reliable water delivery for agriculture, household, and industrial uses, even in challenging or remote locations.

Durable and Corrosion-Resistant Construction

Crafted with stainless steel components and rust-resistant features, the pump ensures long service life and consistent performance. The hermetically sealed enclosure protects internal parts, while the heavy-duty ball bearings easily withstand continuous operation in demanding water supply scenarios.

Advanced Safety and Energy Efficiency

Equipped with IP68 protection, overload protection, and mechanical seals, this pump prioritizes user safety and dependable operation. Energy-efficient design reduces running costs, making it an economical choice for those requiring high flow rates or prolonged usage.

FAQ's of Water Filled Submersible Pump:

Q: How does the water filled submersible pump operate and what makes it suitable for deep water extraction?

A: This pump operates by fully submerging itself in water, eliminating the need for priming. Its multistage centrifugal design and robust materials allow it to function reliably at depths up to 50 meters, making it ideal for deep wells or underground water sources.

Q: What materials are used in the construction of this pump, and how do they contribute to durability?

A: The pump is built with high-grade stainless steel and features noryl or stainless steel impellers. This combination, along with heavy-duty ball bearings and a hermetically sealed enclosure, ensures exceptional corrosion resistance and a long operational lifespan, even in challenging environments.

Q: Where can this submersible pump be installed and what are its typical applications?

A: It is specifically designed for agricultural irrigation, domestic water supply, and industrial applications. Its high-pressure capability and submersible design allow installation in wells, tanks, sumps, and other deep water sources, providing reliable water delivery wherever needed.

Q: What is the recommended water depth for installation and the maximum submersion capability?

A: The pump requires a minimum water depth of 1 meter for proper operation and can be submerged up to a maximum of 50 meters, ensuring flexibility for both shallow and deep installation needs.

Q: How does the pump ensure safety and efficiency during operation?

A: Safety is prioritized through its IP68-rated enclosure, mechanical seals, and built-in overload protector. The energy-efficient motor operates at 2880 RPM, delivering high flow with low noise and reduced energy consumption, effectively lowering running costs.

Q: What are the usage benefits of choosing this water filled submersible pump for water supply or irrigation?

A: Users benefit from high flow rates (up to 8,000 LPH), strong discharge pressure (up to 7 bar), and reliable, low-maintenance operation. Its resistance to rust and low noise operation further enhance its suitability for continuous use in agricultural, domestic, and industrial settings.

Q: What is the process for installing or maintaining this submersible pump?

A: Installation involves lowering the pump into the water source at the desired depth and ensuring secure electrical connections. Maintenance is minimal due to the sealed structure, but regular inspections and occasional cleaning help prolong its service life.
